Automatic Sperm Analyzer

Product number： QA-3

Instrument introduction:
Applying new computer image processing analysis technology and advanced artificial intelligence technology to high-tech intelligent products of modern reproductive medicine,  analyze the sperm of animals such as pigs, cows, sheep, horses, donkeys, dogs, fish, mice, etc.automatic identification of animal sperm, automatic tracking of sperm movement trajectory, can quickly and automatically complete the WHO Multiple parameter analysis of the fifth edition of the international standard, comprehensive quantitative analysis of sperm activity and static characteristics, suitable for clinical semen testing, and provides an important scientific basis for animal fertility testing.

Instrument features:
One-click, fully automatic, standardized, fast and accurate.


working principle:
The fully liquefied and pre-insulated semen samples are placed in a special counting plate after mixing, and the sperm image is enlarged and digitally input into the computer through the microscopic image acquisition system, and displayed on the screen at the same time. Under the control of computer software, the automatic microscope automatically scans the sperm image under the microscope and records the sperm movement trajectory. Through software analysis, the standard parameters such as the density, viability rate and viability level of the sample are calculated.

The main technical parameters:
1. We can analyze the sperm of animals such as pigs, cows, sheep, horses, donkeys, dogs, fish, mice, etc.
2. The system design follows the fifth edition of the WHO Laboratory Manual for Human Semen and Sperm-Cervical Mucus Interaction.
3. Simple operation. Guided operation, get started quickly.
4. There is no limit to the number of collection pictures, which can be collected as needed.
5. Track detection adopts a single-view full image synchronous processing and analysis algorithm, and the track is accurate.
6. The function of detecting and analyzing more than 30 sperm parameters, such as sperm density, sperm motility rate, sperm movement trajectory, sperm movement distribution map, and total sperm count, and morphological analysis function. The detection parameters are rich.
7. The software can quickly, accurately and objectively detect various parameters of the dynamic (static) state of sperm, such as the movement speed and density of sperm, and display it in the form of movement trajectory. Displayed as a percentage.
8. The inspection items are complete, covering most of the semen analysis items, including semen physical properties, sperm microscope kinetic analysis, morphological analysis, sperm function experiments, and chemical analysis items
9. The sperm dynamics analysis project follows the international industry computer CASA standard on the basis of WHO standardization. The vitality level is divided into three levels: PR, NP, and IM, and all relevant parameters of the standard can be analyzed;
10. Sperm morphological analysis module, based on WHO standardization, subdivides various deformity types and deformity rates, and detects a number of morphological indicators.
11. It can track the sperm movement trajectory and draw and output color trajectory lines. The color of the trajectory lines can be set freely, and the sperm can be counted and displayed in sequence numbers;
12. It can filter out various impurities different from sperm morphology to ensure the accuracy of detection.
13. The non-invasive detection sample pool adopts a standard semen counting board , which not only ensures the natural movement of sperm, but also ensures monolayer sampling.
14. After the sperm image is digitally morphologically recognized, the number is automatically assigned, the single sperm is numbered independently, the color of the trajectory curve is optional, and its motion trajectory is accurately tracked and identified to obtain more accurate motion parameters and statistical parameters, which greatly improves the accuracy.
15. Support the unified review function after the collection of multiple specimens is completed, which effectively improves work efficiency.
16. Support review image function playback, effectively avoid missed detection and false detection.
17. The print report can be flexibly set according to your own needs, and new items can be added independently.
18. Support network server sharing, which can be sent to network ports such as LIS/HIS.
19. A powerful computer can quickly store various specimen information and images, and can be recalled to view and print at any time.
20. The query function supports flexible statistics of specimen data.
21. The test results support independent modification and adjustment.
22. Supporting consumables.
23. High definition microscope.

Fully automatic control function:

1. Support software to control the horizontal (X-axis) and vertical (Y-axis) free movement of the microscope platform with an accuracy of 0.25um.

2. Support software to control the up and down movement of the microscope platform (Z axis) to adjust the focal length, support automatic focusing, and the accuracy is 0.025um.

3. Support software control to set light brightness (level 0-99)

4. Unattended function; the software starts with one key, and automatically controls the microscope to perform the functions of focusing, collecting and analyzing specimens, without manual intervention in the whole process. The instrument resets automatically after execution.

5. One can flexibly choose and analyze 1-4 channel samples at a time.
